Autonomous Exploration and Mapping Payload Integrated on a Quadruped Robot

Abstract

The world is rapidly moving towards advancing and utilizing artificial intelligence and autonomous robotics. The Boston Dynamics quadruped robot, Spot, was designed for industrial and commercial tasks requiring limited autonomous navigation. There are a few successful methods to enable an autonomous explorer Spot system. Still, none of them made it to the application level due to complexity, weight, and occupying the entire back of the Spot robot, leaving very limited or no space to integrate other sensors or payloads for different purposes. The state-of-the-art autonomous system solution requires at least three depth cameras, a single LiDAR scanner, an extended GPU-dependent computer, extended power, specific hardware, an extended battery, a base station for command and control, and 3-4 people to operate. Our research aims to reduce the complexity of hardware, software, and operation to achieve a usable autonomous system. Our research uses fewer and less expensive sensors and, importantly, operates in GPS-denied scenarios, with only one person to manage and no base station needed to command and control. Our autonomy stack runs on our single Spot CORE i5 computer mounted on the back of the robot. The operator controls the area of exploration, defines the operational zone and sends the command to have Spot explore, generate 2D and 3D maps of the environment, and return to the start location to await the operator’s command. It is possible to enhance the Spot robot with a simplified autonomy module and utilize it in many tasks, including disaster response, nuclear inspection, mine inspection, etc. Other less extreme use cases include autonomous 3D and 2D scanning of facilities for inspection, engineering, and construction purposes. We describe the system design, its implementation, and a number of experiments.
